Variflow Dosing Metering Diaphragm Pumps - Z Series Vertical
The Variflow Dosing Metering Plunger Pumps - Z series Vertical is from 0 - 14000 LPH giving a
maximum pressure of 300 Bar depending upon the flow rate.
These pumps are provided with high efficiency ball valves & high grade of engineering materials for
the wetted parts, which enables wide range
of aggressive, toxic, hazardous liquid to be handled.
These pumps are available in multi heads upto 3 heads. The pump head are manufactured from Stainless
Steel Material.
Technical Details
| CAPACITY | 1500 L/Hr (Max) |
| PRESSURE | 10 Bar (Max) |
| PUMP HEAD |
SS304 / SS316 / SS316L or any other as per required |
| PORT CONNECTION |
BSP (F) Standard (other options on request) |
| MOTOR TYPE |
Standard / Flame Proof / VFD Compatible / Energy Efficient (other options on request) |
| MOTOR POWER |
0.5 – 2 HP, RPM 1450 Single Phase / Three Phase, 50 Hz / 60 Hz 230 V / 380 V / 415 V (other options on request) |
| APPLICATIONS | Dosing / Metering / Injection / Mixing / Treatment / Feeding / Transfer / Sampling |
PRODUCT CHART - Z SERIES VERTICAL
| PUMP MODEL | 75 SPM (LPH) | 100 SPM (LPH) | 150 SPM (LPH) | 200 SPM (LPH) | PRESS. (KG/CM²) | END CONNECT | MOTOR |
|---|---|---|---|---|---|---|---|
| Z - A | 4.5 | 6 | 9 | 12 | 30 | 1/2" | 0.5 HP |
| STROKE | 11 | 18 | 27 | 40 | 20 | ||
| LENGTH | 22 | 33 | 50 | 68 | 10 | ||
| 10 MM | 30 | 44 | 70 | 100 | 5 | ||
| 12 MM | 40 | 75 | 115 | 160 | 4 | ||
| Z - B | 3 | 4.5 | 6 | - | 300 | 1" | 1 HP |
| STROKE | 18 | 28 | 43 | - | 80 | ||
| LENGTH | 70 | 95 | 155 | - | 20 | ||
| 20 MM | 160 | 215 | 325 | - | 10 | ||
| 25 MM | 310 | 420 | 610 | - | 4 | ||
| Z - C | 11 | 14 | 22 | - | 300 | 1 ½" | 2 HP |
| STROKE | 43 | 56 | 90 | - | 80 | ||
| LENGTH | 130 | 174 | 260 | - | 25 | ||
| 30 MM | 385 | 511 | 775 | - | 10 | ||
| 35 MM | 770 | 1026 | 1550 | - | 5 | ||
| Z - D | 20 | 30 | 40 | - | 300 | 2" | 3 HP |
| 40 MM | 1500 | 2000 | 3000 | - | 5 | ||
| Z - F | 200 | 225 | 395 | - | 75 | 2" | 5 HP |
| 60 MM | 3100 | 5000 | 6200 | - | 5 | ||
| Z - I | 1550 | 1550 | 2300 | - | 50 | 3" | 12.5 HP |
| 90 MM | 7250 | 9700 | 14000 | - | 7 | ||
*** Our policy is to continually develop and improve our products and we therefore reserve the right to modify products without any notice.***
