Fixflow Dosing Metering Plunger Pumps - HPS Series
The Fixflow Dosing Metering Plunger Pumps - HPS series is from 25 - 136 LPH giving a maximum pressure of 260 Bar depending upon the flow rate.These pumps are provided with high efficiency ball valves & high grade of engineering materials for the wetted parts, which enables wide range of aggressive, toxic, hazardous liquid to be handled. The pump head are Manufactured from Stainless Steel Material.
Technical Details
| CAPACITY | MAX - 136 LPH |
| PRESSURE | MAX - 260 BAR |
| MOC |
SS 304 / SS 316 / SS 316 L or any other as required |
| MOTOR POWER | 0.5 HP - 2 HP, RPM : 1450 |
| MOTOR TYPE | STANDARD / FLAME PROOF / VFD COMPATIBLE / ENERGY EFFICIENT |
| POWER SUPPLY | SINGLE / THREE PHASE, 50/60 HZ, 230V / 380V / 415V |
| APPLICATION | DOSING / METERING / INJECTION / MIXING / FEEDING / SAMPLING |
PRODUCT CHART – HPS SERIES
| WORKING CAPACITY (LPH) | WORKING PR. (KG/CM²) | SPEED (SPM) | END CONNECT | MOTOR HP (RPM 1450) |
|---|---|---|---|---|
| 25 | 85 / 130 / 175 / 260 | 100 | 1/4" BSP | 0.5 / 0.75 / 1.0 / 1.5 |
| 36 | 95 / 130 / 195 / 200 | 100 | 1/4" BSP | 0.75 / 1.0 / 1.5 / 2.0 |
| 54 | 85 / 130 / 170 | 100 | 1/4" BSP | 1.0 / 1.5 / 2.0 |
| 68 | 100 / 140 | 100 | 1/4" BSP | 1.5 / 2.0 |
| 91 | 75 / 100 | 100 | 1/2" BSP | 1.5 / 2.0 |
| 113 | 60 / 80 | 100 | 1/2" BSP | 1.5 / 2.0 |
| 136 | 50 / 70 | 100 | 1/2" BSP | 1.5 / 2.0 |
*** Our policy is to continually develop and improve our products and we therefore reserve the right to modify products without any notice.***
